| Item Number | TH-UVF9D |
| General | |
| Frequency Range |
70-108MHz(FM Radio only) ;
134.000-174.000MHz 350.000-399.999MHz ; 400.000-480.000MHz |
| Frequency Stability | ±2.5ppm |
| Channel No. | 128 |
| Operating Voltage | DC 7.2V |
| Antenna | High gain antenna |
| Antenna Impedance | 50Ω |
| Mode of operation | Simple or semi-duplex |
| Dimension（W x H x D） | 128*63*33 mm |
| Transmitter | |
| Output power | VHF:5W UHF:4W |
| Modulation Mode | 16kΦF3E / 11kΦF3E |
| Maximum deviation | ＜5kHz / ＜2.5kHz |
| Spurious Radiation | ＜7μW |
| Pre-emphasis characteristics | 6dB |
| Current | ≤1.6A(5W) |
| CTCSS/DCS deviation | 0.5 kHz±0.1kHz / 0.3±0.1kHz |
| Intermediation sensitivity | 8-12mv |
| Intermediation distortion | ＜5% |
| Receiver | |
| RF Sensitivity | -122dbm(12db SINAD) |
| Audio power | 1W |
| Audio Distortion | <5% |
| Blocking | ≥85dB |
| Intermediation | ≥60dB ≥55dB |
| Selectivity | ≥65dB ≥60dB |
| Spurious Rejection | ≥65dB |
